Workpiece type: frame

1.2, the maximum size of mm: 1000 x 1200 (mm)

1.3, the maximum workpiece weight: less than 50kg.

1.4, the work piece conveying equipment: chain structure suspension type automatic line

1.5, before the following way: all spray way

1.6, spray painting way: DISC automatic spray painting, manual repair spray

1.7, paint treatment: washing outside the row

1.8, the number of guns: spray paint 1

1.9, with anti - flammable and explosive devices, in accordance with the "GB14444-1993" GB5008-1992 "paint room safety technical requirements" and the "explosion and fire dangerous places, power plant design specifications" requirements

1.10, equipment noise in line with GBJ87-85 "industrial enterprise noise control design code"

1.11, exhaust emissions in line with the GB16297-1996 "comprehensive emission standards for atmospheric pollutants".

1.12, safety measures: the system has interlocking interactive safety devices, to ensure that equipment, personal safety.
